Q7022 180m 16t Safety Construction Tower Crane 2000x2000x3000mm

Name: Q7022 180m 16t Safety Construction Tower Crane 2000x2000x3000mm
Brand: XCMG
Price: 1 USD

Buy cheap Q7022 180m 16t Safety Construction Tower Crane 2000x2000x3000mm product

Brand Name : XCMG

Model Number : Q7022

Certification : ISO CE

Place of Origin : China

MOQ : 1pc

Price : negotiate

Supply Ability : 10000pcs/year

Packaging Details : RO-RO CONTAINER

Max Lift : 16 ton

Model : Q7022

Rated load moment : 2744 KN.M

Boom length : 70m

Fixed height : 51.7m

Max Height : 180m

Section Size : 2000x2000x3000

Contact Now

Big lifing capacity XCMG Q7022 16t strong and simple Tower Crane

Quick Details:

Name: Tower crane Max. Lifting Capacity: 16 ton

Max. Lifting Moment: 20 T.M Base height: 51.7m

Max. height:180meter Brand: XCMG

Tip load: 2,2T Hosting speed: 0-30

Steel structure highlights:

The tower body is a standard section with convenient transportation and high interchangeability;
Using of adding section method, to make section convenient, safe, high efficiency;
A large number of Q345B material and steel structure weight is light, high bearing capacity,

long service life.The lifting and balance arm and rotating tower with card plate,make tower crane

safe and convenient.

Specifications:

Parameter term	Q7002	-
Luffing tower crane	Q7022(7022-16)	-
Arm length (m) / arm end lifting weight	70/2.2	(t)
Rated lifting moment	280	(t.m)
Maximum weight	16	(t)
Fixed height	51.7	(m)
Attached height	180	(m

Q7022 180m 16t Safety Construction Tower Crane 2000x2000x3000mm

Dimension drawing

Work pictures:

Q7022 180m 16t Safety Construction Tower Crane 2000x2000x3000mm
